How To Use Python struct Module for Binary Data Packing
Last Updated: June 01, 2026
Intermediate
Most Python code deals with strings, JSON, and high-level data structures. But some problems take you closer to the metal: parsing a binary file format, reading sensor data over a serial port, implementing a network protocol, or working with legacy data from a C program. At that level, you are not dealing with JSON objects — you are dealing with raw bytes, and the layout of those bytes follows a precise binary format that Python’s JSON parser cannot touch. This is the domain of Python’s struct module.
The struct module lets you pack Python values into raw bytes and unpack raw bytes back into Python values, following an exact layout you specify with a format string. It handles integer sizes, floating-point precision, byte order (little-endian vs big-endian), and alignment — exactly the things you need to interoperate with compiled code, hardware, or binary file formats. No third-party installation required — struct is part of Python’s standard library.
In this tutorial, you’ll learn how struct format strings work, how to pack and unpack individual values and records, how byte order affects your data, how to work with fixed-size binary file headers, and how to handle variable-length data. By the end, you’ll be able to read and write binary data formats with confidence.
Python developer and educator with 15+ years building production systems across data engineering, web APIs, and AI tooling. Founder of Python How To Program — 270+ in-depth tutorials covering the modern Python stack.
View all tutorials by Pubs →Python struct: Quick Example
Here is a minimal example that packs three Python values into 10 bytes and unpacks them back:
# struct_quick.py
import struct
# Pack: 'I' = unsigned int (4 bytes), 'H' = unsigned short (2 bytes), 'f' = float (4 bytes)
fmt = 'IHf'
data = struct.pack(fmt, 1000, 42, 3.14)
print(f"Packed bytes ({len(data)} bytes): {data.hex()}")
print(f"Calculated size: {struct.calcsize(fmt)} bytes")
# Unpack: reverse the process
user_id, status, temperature = struct.unpack(fmt, data)
print(f"Unpacked: user_id={user_id}, status={status}, temperature={temperature:.4f}")
Output:
Packed bytes (10 bytes): e80300002a00c3f54840
Calculated size: 10 bytes
Unpacked: user_id=1000, status=42, temperature=3.1400001049041748
Three Python values become 10 bytes of binary data. struct.pack() encodes them, struct.unpack() decodes them. The format string 'IHf' describes the exact layout: a 4-byte unsigned int, a 2-byte unsigned short, and a 4-byte float. The slight floating-point difference is normal — 32-bit IEEE 754 floats cannot represent 3.14 exactly.
Understanding Format Strings
The format string is the core of struct. Each character represents a C data type with a fixed byte size. You can add a number prefix to repeat a character (e.g., '3B+ for three bytes).
| Format Char | C Type | Python Type | Size |
|---|---|---|---|
b | signed char | int | 1 byte |
B | unsigned char | int | 1 byte |
h | short | int | 2 bytes |
H | unsigned short | int | 2 bytes |
i | int | int | 4 bytes |
I | unsigned int | int | 4 bytes |
q | long long | int | 8 bytes |
Q | unsigned long long | int | 8 bytes |
f | float | float | 4 bytes |
d | double | float | 8 bytes |
s | char[] | bytes | 1 byte each |
? | bool | bool | 1 byte |
The first character of the format string optionally specifies byte order. '<' means little-endian (x86, ARM, most modern hardware), '>' means big-endian (network byte order, some file formats), and '=' means native byte order without alignment padding.
# byte_order.py
import struct
value = 0x01020304 # = 16909060 decimal
little_endian = struct.pack('I', value)
print(f"Value: {value:#010x}")
print(f"Little-endian bytes: {little_endian.hex()}") # Least significant byte first
print(f"Big-endian bytes: {big_endian.hex()}") # Most significant byte first
# Verify round-trip
le_val = struct.unpack('I', big_endian)[0]
print(f"LE decoded: {le_val:#010x}")
print(f"BE decoded: {be_val:#010x}")
Output:
Value: 0x01020304
Little-endian bytes: 04030201
Big-endian bytes: 01020304
In little-endian, the least significant byte comes first: 04, 03, 02, 01. In big-endian, the most significant byte comes first: 01, 02, 03, 04. Most PC hardware is little-endian. Network protocols (TCP/IP) use big-endian. When working with an unknown format, look up whether it specifies byte order — getting it wrong produces silently corrupted values.
Packing and Unpacking Records
The real power of struct is packing multiple related values into a compact binary record — and unpacking them back. This is how binary file headers, network packets, and sensor data frames are built.
Fixed-Size Records
When all records have the same format, use a single format string and loop over the data with iter_unpack() for efficiency:
# struct_records.py
import struct
# Format: timestamp (4B uint), sensor_id (2B uint), temperature (4B float), humidity (4B float)
RECORD_FMT = 'Output:
Record size: 14 bytes
Wrote 3 records (42 bytes)
Read 42 bytes
Parsed records:
t=1706000001, sensor=1, temp=22.5C, humidity=65.3%
t=1706000002, sensor=2, temp=23.1C, humidity=63.8%
t=1706000003, sensor=1, temp=22.8C, humidity=64.1%
struct.iter_unpack() is the efficient way to read a stream of same-format records. It yields tuples one at a time without buffering the whole dataset, which matters when reading large binary files.
Packing String Fields
Strings in struct are fixed-length byte fields. Use 'Ns' (e.g., '20s') for a string of exactly N bytes. Shorter strings must be padded; longer strings are truncated.
# struct_strings.py
import struct
NAME_LEN = 20
FMT = f'<{NAME_LEN}sI' # 20-byte name string + 4-byte uint score
def pack_player(name: str, score: int) -> bytes:
# Encode to bytes and truncate/pad to exactly NAME_LEN bytes
name_bytes = name.encode('utf-8')[:NAME_LEN].ljust(NAME_LEN, b'\x00')
return struct.pack(FMT, name_bytes, score)
def unpack_player(data: bytes) -> tuple:
name_bytes, score = struct.unpack(FMT, data)
name = name_bytes.rstrip(b'\x00').decode('utf-8') # Strip null padding
return name, score
players = [
("Alice", 9500),
("Bob", 7200),
("CharlieLongNameHere", 3400),
]
packed = b''.join(pack_player(n, s) for n, s in players)
print(f"Total size: {len(packed)} bytes ({len(players)} x {struct.calcsize(FMT)} bytes each)")
print("\nUnpacked players:")
record_size = struct.calcsize(FMT)
for i in range(0, len(packed), record_size):
name, score = unpack_player(packed[i:i + record_size])
print(f" {name!r}: {score}")
Output:
Total size: 72 bytes (3 x 24 bytes each)
Unpacked players:
'Alice': 9500
'Bob': 7200
'CharlieLongNameHer': 3400
The long name "CharlieLongNameHere" gets truncated to 19 characters (19 bytes fit in the 20-byte field; [:NAME_LEN] handles this). Null bytes are stripped on unpack with .rstrip(b'\x00'). Always check encoding: if names can contain non-ASCII characters, use 'utf-8' and note that some characters take 2-4 bytes each, which can change how many characters fit in the fixed field.
Reading Binary File Headers
Many binary file formats start with a fixed-size header that describes the file's contents. Here is an example of writing and reading a custom binary file format with a header:
# binary_file_format.py
import struct
from pathlib import Path
# File format:
# Header (16 bytes):
# - magic: 4 bytes (b'PYDB')
# - version: 2 bytes (uint16)
# - record_count: 4 bytes (uint32)
# - record_size: 2 bytes (uint16)
# - flags: 4 bytes (uint32)
# Records follow the header
HEADER_FMT = '>4sHIHI' # Big-endian (common for file formats)
HEADER_SIZE = struct.calcsize(HEADER_FMT)
MAGIC = b'PYDB'
RECORD_FMT = '>If' # Big-endian: int32 id + float32 value
RECORD_SIZE = struct.calcsize(RECORD_FMT)
def write_db(path: Path, records: list[tuple]):
with open(path, 'wb') as f:
# Write header
header = struct.pack(
HEADER_FMT,
MAGIC,
1, # version
len(records), # record_count
RECORD_SIZE, # record_size
0, # flags (unused)
)
f.write(header)
# Write records
for rec_id, value in records:
f.write(struct.pack(RECORD_FMT, rec_id, value))
def read_db(path: Path) -> list[tuple]:
with open(path, 'rb') as f:
raw_header = f.read(HEADER_SIZE)
magic, version, count, rec_size, flags = struct.unpack(HEADER_FMT, raw_header)
if magic != MAGIC:
raise ValueError(f"Not a PYDB file: {magic}")
print(f"File: magic={magic}, version={version}, records={count}, rec_size={rec_size}")
records = []
for _ in range(count):
raw = f.read(rec_size)
rec_id, value = struct.unpack(RECORD_FMT, raw)
records.append((rec_id, value))
return records
# Demo
data = [(1001, 98.6), (1002, 37.2), (1003, 100.1), (1004, 36.9)]
path = Path("readings.pydb")
write_db(path, data)
print(f"File size: {path.stat().st_size} bytes (header {HEADER_SIZE} + {len(data)} x {RECORD_SIZE})")
records = read_db(path)
print("Records:", records)
path.unlink()
Output:
File size: 48 bytes (header 16 + 4 x 8)
File: magic=b'PYDB', version=1, records=4, rec_size=8
Records: [(1001, 98.5999984741211), (1002, 37.20000076293945), (1003, 100.0999984741211), (1004, 36.90000152587891)]
The file is exactly 48 bytes: 16 bytes of header plus 4 records of 8 bytes each. The magic bytes b'PYDB' let the reader verify it is the right format before processing. The slight float differences are expected from 32-bit float precision -- use d (double) instead of f (float) if you need full precision.
Real-Life Example: BMP Image Header Parser
The BMP (Windows Bitmap) image format has a well-documented binary header. Here is a parser that reads the header from any BMP file and reports its dimensions, color depth, and compression:
# bmp_header_parser.py
import struct
from pathlib import Path
# BMP File Header (14 bytes, little-endian)
FILE_HEADER_FMT = '<2sIHHI'
FILE_HEADER_SIZE = struct.calcsize(FILE_HEADER_FMT)
# DIB Header -- BITMAPINFOHEADER (40 bytes, little-endian)
DIB_HEADER_FMT = ' dict:
with open(path, 'rb') as f:
raw_file_hdr = f.read(FILE_HEADER_SIZE)
raw_dib_hdr = f.read(DIB_HEADER_SIZE)
# Parse file header
sig, file_size, reserved1, reserved2, data_offset = struct.unpack(FILE_HEADER_FMT, raw_file_hdr)
if sig != b'BM':
raise ValueError(f"Not a BMP file (signature: {sig})")
# Parse DIB header
(dib_size, width, height, planes, bpp, compression,
img_size, x_ppm, y_ppm, colors_used, colors_important) = struct.unpack(DIB_HEADER_FMT, raw_dib_hdr)
return {
'file_size_bytes': file_size,
'data_offset': data_offset,
'width': abs(width),
'height': abs(height),
'bits_per_pixel': bpp,
'compression': COMPRESSION.get(compression, f'Unknown ({compression})'),
'image_size_bytes': img_size,
}
# Create a minimal valid 2x2 BMP for demo
def create_tiny_bmp(path: Path):
"""Create a 2x2 24-bit BMP (white pixels)."""
width, height, bpp = 2, 2, 24
row_size = (width * 3 + 3) & ~3 # Rows padded to 4-byte boundaries
img_data = b'\xff\xff\xff' * width + b'\x00' * (row_size - width * 3)
img_data = img_data * height
dib = struct.pack(DIB_HEADER_FMT, 40, width, -height, 1, bpp, 0, len(img_data), 2835, 2835, 0, 0)
file_hdr = struct.pack(FILE_HEADER_FMT, b'BM', FILE_HEADER_SIZE + DIB_HEADER_SIZE + len(img_data), 0, 0, FILE_HEADER_SIZE + DIB_HEADER_SIZE)
with open(path, 'wb') as f:
f.write(file_hdr + dib + img_data)
bmp_path = Path("test.bmp")
create_tiny_bmp(bmp_path)
info = parse_bmp(bmp_path)
print("BMP Header Info:")
for key, value in info.items():
print(f" {key}: {value}")
bmp_path.unlink()
Output:
BMP Header Info:
file_size_bytes: 70
data_offset: 54
width: 2
height: 2
bits_per_pixel: 24
compression: None (RGB)
image_size_bytes: 8
This parser works on any valid BMP file -- save a screenshot as .bmp and point it at that file to see the real dimensions and color depth. The format string mirrors the exact binary layout of the BMP spec, and struct.unpack() does all the byte-level decoding.
Frequently Asked Questions
When should I use struct vs other binary libraries?
Use struct for simple, fixed-layout binary formats where you know the exact byte positions. Use ctypes when interoperating directly with C shared libraries. Use construct (third-party) for complex binary formats with conditionals, enums, and nested structures. Use numpy when working with arrays of numeric data -- numpy dtype handling is faster for bulk array operations than looping with struct.
How do I know which byte order to use?
Check the format specification of whatever you are reading or writing. Network protocols (TCP, UDP, most internet standards) use big-endian ('>'). Most PC hardware (x86, ARM) is little-endian ('<'). File formats vary: PNG and BMP headers are little-endian, TIFF can be either (and specifies in the file itself), audio WAV is little-endian. When in doubt, use explicit '<' or '>' prefix rather than relying on native order.
What is struct alignment and padding?
By default ('@' byte order), struct adds padding between fields to align them on natural boundaries, just like a C compiler would. A 4-byte int after a 1-byte char gets 3 bytes of padding inserted. Use '=' (native order, no padding) or '<'/'>' (explicit endian, no padding) to disable this. Most binary file formats specify exact byte positions with no padding, so you almost always want '<' or '>'.
What does struct.error mean?
struct.error is raised when the data buffer is too short for the format (not enough bytes to unpack), when a value is out of range for the target type (e.g., 300 for a signed byte), or when the format string is invalid. Always check that len(data) == struct.calcsize(fmt) before calling unpack(), and catch struct.error when parsing untrusted binary data.
How do I read partial structs or variable-length data?
For variable-length data, use a fixed-size header that contains a length field, then read that many bytes. Pattern: header = struct.unpack('>I', f.read(4))[0] reads a 4-byte length, then data = f.read(header) reads the payload. This is the standard framing pattern used in virtually every binary protocol that includes variable-length fields.
Conclusion
Python's struct module bridges the gap between Python's high-level data types and the raw binary world. The key skills are writing format strings with the right type codes (I, H, f, s, etc.), choosing the correct byte order prefix ('<' for little-endian, '>' for big-endian), and using calcsize() to verify your layout before committing to it. For reading streams of same-format records, iter_unpack() is the efficient choice over a manual loop.
The BMP parser and sensor data examples in this article represent the two most common use cases: parsing an existing binary format and designing your own. Both follow the same pattern: define the format string, pack or unpack with a single call, and handle byte order explicitly. Extend the sensor example by adding a checksum field ('I' at the end, computed as the XOR of all bytes) for data integrity validation.
For the complete format string reference and edge cases, see the official struct documentation. The array module is also worth knowing for typed arrays of uniform numeric values.
